| Guargum Processing | |||
|---|---|---|---|
| Sr. No. | Machine Name | Specification | Quantity-Unit |
| 1 | Bucket Elevator | Material of Construction M.S, Size: 23 35760mm 250mm Approx, with Upper and bottom hood of 3.00mm sheet pipe, Belt: Thar Rubber Belt Bucket Size: 125mm 125mm Appros. |
6 Nos. |
| 2 | Rotary Siever three sheet | Material of Construction: Mild Steel, Size 3048 1143 1829 mm approx no, of screen-3, Stue of rach screen: 915 3050 mm Shaft: Dia.10mm. |
1 Nos. |
| 3 | Cracking Mill Horizontal Type- 24" | Capable for continuous use of 24 Hrs. Material of Construction: M.S, dimension: 1447 762 mm Approx, Stone Size: 609mm Appras, |
1 Nos. |
| 4 | Model Double Deck Rotary Siever Dust Proof |
Material of Construction: M.S., Size: 3100 1143 3352 mum approx. Size of each screen: 915 3050 mm Number of screen: 6. Shaft: Dix.50mm Drive: By gear box |
2 Nos. |
| 5 | Pin Mill (pulvisour | Dia.- 406 mm | 2 Nos. |
| 6 | Single Drum Roasting Unit | Complete Structure with firebricks & insulation. Structure Size: 3960 1219 1143mm Appras, without any foundation & stand |
1 Nos. |
| 7 | Roaster Operating System | Burner & blower, Fuel: Diesel or if gossifayer, fuel | 1 Nos. |
| 8 | DE Husking Machine (Gum Machine) | Material of Construction: M.5.& C.1. side plate- 12mm, drum-6 mm plate upper machine 33 blade. lower 31 blade |
1 Pair |
| 9 | Separator | Material of Construction: M.S., No. of Screens: two Size of Each screen: 915 2438 5mm, Changeable sieves for surface screening Impellar: Dynamically Balanced, Aspirator Fan. Number of aspiration. Τίνα Variable air controls |
1 Nos. |
| 10 | Rotary Siever Single Position | Material of Construction: M.S., Size: 2184 990 1524 mim Approx, Size of screen: 915*2440mm Approx. Number of Screens: 2, Shaft: Dia.50mm |
3 Nos. |
| 11 | Rotary Siever Single Position | Material of Construction: M.S. Size: 2184 1143 1524 min Approx. Size of screen: 915 3048mm Approx., Number of Screens: 2, Shaft: Din, 50mm |
1 Nos. |
| 12 | Pneumatic System Comprising | With all required various size blowers, cyclones, Full and half Bends, Airlocks, pipe. | 2 Nos. |
| 13 | Dust collector | 1 Nos. | |
| A | Plant Fitting, Erection & Comissioning Training | 1 Nos. | |
| B | Electric Motor, Panel, Cable, P.F. Penal Cost | 1 Nos. | |
| C | Transport, Loading, Conveying | 1 Nos. | |
| D | Accommodation | 1 Nos. | |
| E | Storage Bins | 1 Nos. |
| Sr. No. | Machine Name | Quantity |
|---|---|---|
| 1 | Capacity: 1MT/hr, Conveyor, Transition piece, Full circle hammer mill, Conveyor, Transition piece, Storing bin Mixture, Conveyor, Transition Piece, Pellet Mill 16", Electricity Motors, panels, & Accessories, V belt pouli machine oil ete. Fitting and Commissioning Training |
1 Set |
| 2 | Automatic packaging unit for Split and Powder/Husk with Utilities and Erection, Commissioning and Training. | 1 set each |
